3D Aluminum Architectural Cladding
Created with Pixso.

3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding

3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding

Brand Name: M-CITY
Model Number: MCT-solid wall cladding
MOQ: 80square meters
Price: USD25-USD55/square meter
Supply Ability: 60000sq.m
Detail Information
Product Description
Detail Information
Place of Origin:
Guangzhou, China
Certification:
ISO9000
Material:
Aluminum Alloy
Recommand Size:
1000x2000mm
Aluminum Thickness:
3mm,2mm, 2.5mm, 4mm To 10mm
Surface Treatment:
Powder Coated, Pvdf Paint, Wood Grain
Color:
Any RAL Color, Wood Grain, Stone Color, Brass, Bronze
Applications:
Window, Fence, Facade, Curtain Wall, Cladding, Decoration, Screen, Balcony
Max. Size:
1600x4000mm
Contact Email:
Mcityalu@163.com
Processing:
Cutting, CNC, Bending, Painting, Assmebly, Inspecting, Packing
Technology:
Perforated, Laser Cutting, CNC Turret Punching , Carved, Engraved
Keywords:
Perforated Metal Facade
Packaging Details:
Export packing, plywood cases, metal cases, protect film+ bubble film
Supply Ability:
60000sq.m
Highlight:

3D aluminum wall panels

,

powder coated metal cladding

,

outdoor laser cut panels

Product Description
3D Aluminum Panels with Laser Cut Design
Premium powder-coated aluminum panels featuring Akzo Nobel coatings, specifically designed for outdoor wall cladding applications. These panels combine durability with aesthetic appeal for modern architectural facades.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 0 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 1 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 2 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 3 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 4 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 5 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 6 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 7 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 8 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 9 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 10 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 11
3D Facade Design Metal Cladding
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 12 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 13
Perforated Aluminum Solid Panels
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 14 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 15
Aluminum Cladding Installation Guide
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 16 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 17
Corrugated Perforated Screen Aluminum Sheet
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 18
CNC Engraved Metal Facade Assembly
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 19
Exterior Aluminum Decorative Panel with Round Holes
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 20
3D Facade Design Metal Cladding Details
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 21
Custom Manufacturing Capabilities
As a professional manufacturer, M-City Aluminum maintains an excellent design team and skilled fabrication workers with advanced CNC facilities. We produce aluminum panels according to customer requirements for dimensions, specifications, shapes, structures, colors, and competitive budgets.
We provide comprehensive support including site measurement by our engineers, shop drawing preparation, and installation guidance to ensure smooth project execution.
Simplified Installation Process
All aluminum panels are prefabricated according to customer designs and drawings. Installation requires only frame preparation, bolts, and sealants for finishing gaps between panels. This makes building envelope and decoration an efficient process.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 22
Product Specifications
Our metal cladding panels are manufactured from high-quality, high-strength aluminum alloy sheets with standard thickness options of 1.5mm, 2.0mm, 2.5mm, and 3.0mm. Maximum sheet dimensions are 2000mm width and 6000mm length, using 3003-H14 or 1100-H14 aluminum alloy series.
Panel Construction
Each panel consists of a main panel, reinforce bar, and bracket. Corner brackets can be directly stamped from the panel or riveted onto small folding edges. Reinforce bars connect to welding screws behind the board surface, creating a solid unit that enhances strength, rigidity, and ensures long-term flatness, wind pressure resistance, and earthquake resistance.
For sound insulation requirements, high-efficiency sound insulation materials can be installed inside the aluminum panel.
Manufacturing Facility
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 23
Global Shipping
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 24
M-City Aluminum factory produces various metal facade panels with perforation designs or laser cut designs. We welcome project requirements for custom facade solutions.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 25
3D Metal Facade Wall Cladding Details
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 26
Frequently Asked Questions
Are you a trading company or factory?
We are a 100% professional manufacturer with more than 50 production machines and over 100 staff members.
Can you accept our own designs?
Yes. Size, color, patterns, and designs can be customized according to your project requirements.
What is your minimum order quantity (MOQ)?
We accept small orders with a minimum of 80 square meters.
What is the delivery time?
Production is completed within 30 days after receiving deposit.
Contact Information
WhatsApp: +86 13631413050
Email: mcityalu@sina.com
Any patterns or designs can be manufactured. Please provide drawings or pictures for customization.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 27
M-CITY Aluminum Facade Cladding Specifications
Aluminum panels are manufactured from 3003 series aluminum alloy sheets. As curtain wall systems, they serve for wall protection and non-lighting walls, replacing traditional mosaic and sandblasting facades. Their light weight and superior strength characteristics make them ideal for high-rise buildings where various loads, particularly wind pressure, are constant concerns.
Traditional mosaic materials are prone to falling off due to high wind pressure and deformation, while aluminum panels offer unique advantages for widespread use in high-rise construction.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 28
Application Versatility
Aluminum hollow panels are suitable for facades, fences, canopies, ceilings, screens, windows, and various architectural applications. Choose patterns from our catalog or provide drawings/pictures for custom designs.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 29
Advanced Manufacturing Technology
We utilize imported CNC cutting machines, punching machines, professional software, and experienced designers. Our extensive project portfolio worldwide ensures reliable performance for your projects.
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 30 3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 31
To meet individual customer requirements, select patterns from our renderings or customize your favorite designs. Our goal is to create the best customized products for each client. Aluminum hollow panel sizes can be adjusted with design element considerations, not simple scaling. Our standard size is 1200x2400mm, with combination options for larger dimensions.
Perforated Aluminum Cladding Project Reference
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 32
Fence Decoration Applications
3D Aluminum Panel with Laser Cut Design and Powder Coated Finish in Customizable RAL Colors for Outdoor Wall Cladding 33
