products details

Created with Pixso. Home Created with Pixso. Products Created with Pixso.
Decorative Laser Cut Panels
Created with Pixso.

Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding

Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding

Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding

Brand Name: M-CITY
Model Number: MCT-metal facades perforated
MOQ: 80square meters
Price: USD25-USD55/square meter
Supply Ability: 60000sq.m
Detail Information
Product Description
Detail Information
Place of Origin:
Foshan, China
Certification:
ISO9000
Material:
Aluminum Alloy
Recommand Size:
1200x2400mm
Aluminum Thickness:
3mm,2mm, 2.5mm, 4mm To 10mm
Surface Treatment:
Powder Coated, Pvdf Paint, Wood Grain
Color:
Any RAL Color, Wood Grain, Stone Color, Brass, Bronze
Applications:
Window, Fence, Facade, Curtain Wall, Cladding, Decoration, Screen, Balcony
Max. Size:
1600x4000mm
Contact Email:
Mcityalu@163.com
Processing:
Cutting, CNC, Bending, Painting, Assmebly, Inspecting, Packing
Technology:
Perforated, Laser Cutting, CNC Turret Punching , Carved, Engraved
Packaging Details:
Export packing, plywood cases, metal cases, protect film+ bubble film
Supply Ability:
60000sq.m
Highlight:

laser cut aluminum cladding panels

,

metal screen panels for laser cutting

,

aluminum laser cut facade panels

Product Description
Laser Cutting Metal Cladding Panels Aluminum Screen
Professional manufacturer M-City Aluminum offers custom laser-cut aluminum cladding panels and screens for architectural facades, featuring advanced CNC fabrication capabilities and comprehensive design support.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 0 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 1 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 2 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 3 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 4 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 5 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 6 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 7 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 8 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 9 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 10 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 11 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 12 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 13 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 14 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 15 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 16 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 17 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 18
3D Facade Design Metal Cladding
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 19 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 20
Perforation Aluminum Solid Panels
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 21 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 22
Aluminum Cladding Installation Guide
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 23 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 24
Corrugated Perforated Screen Aluminum Sheet
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 25
CNC Engraved Metal Facade Assembly
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 26
Exterior Aluminum Decorative Panel with Round Holes
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 27
3D Facade Design Metal Clad Aluminum Details
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 28
As a professional manufacturer, M-City Aluminum maintains an excellent design team and skilled fabrication workers with advanced CNC facilities. We produce aluminum panels according to customer requirements for dimensions, specifications, shapes, structures, colors, and competitive budgets. Our engineers can visit project sites to measure installation specifications and create shop drawings for smooth installation.
All aluminum panels are prefabricated according to customer designs and drawings. Installation requires only frame construction, bolts, and sealants for panel gaps, making building envelope and decoration straightforward.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 29
Product Specifications
Metal cladding panels are manufactured from high-quality, high-strength aluminum alloy sheets with standard thicknesses of 1.5mm, 2.0mm, 2.5mm, and 3.0mm. Maximum sheet width is 2000mm with maximum length of 6000mm, using aluminum alloy series 3003-H14 or 1100-H14.
The system consists of panel, reinforce bar, and bracket. Corner brackets can be directly stamped from the panel or riveted to folding edges. Reinforce bars connect to welding screws behind the board surface, creating a solid structure that enhances strength, rigidity, flatness, and resistance to wind pressure and earthquakes. Sound insulation materials can be installed inside panels when required.
Manufacturing Facility
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 30
Global Shipping
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 31
M-City Aluminum factory produces various metal facade panels with perforation or laser cut designs. We welcome project requirements for custom facade designs.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 32
3D Metal Facade Wall Cladding Details
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 33
Frequently Asked Questions
Are you a trading company or factory?
We are a 100% professional manufacturer with more than 50 production machines and over 100 staff members.
Can you accept our own designs?
Yes. Size, color, patterns, and designs can be customized according to your project requirements.
What is your minimum order quantity?
We accept small orders with a minimum of 80 square meters.
What is the delivery time?
Production is completed within 30 days after receiving deposit.
Contact Information
WhatsApp: +86 13631413050
Email: mcityalu@sina.com
Any patterns or designs can be manufactured. Please provide drawings or pictures for custom production.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 34
M-CITY Metal Aluminum Facade Cladding Specification
Aluminum panels are manufactured from Aluminum alloy 3003 series sheets, serving as curtain walls for wall protection and non-lighting walls. They replace mosaic and general sandblasting facades with light texture and excellent strength characteristics, making them ideal for high-rise buildings where wind pressure and deformation resistance are critical.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 35
Aluminum hollow panels are used for facades, fences, canopies, ceilings, screens, windows, and other applications. Choose patterns from our catalog or provide drawings/pictures for custom design.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 36
Advanced CNC Cutting Technology
With imported CNC cutting machines, punching machines, professional software, experienced designers, and global project experience, we ensure reliable project execution.
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 37 Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 38
We accommodate individual customer requirements by offering pattern selection from renderings or custom pattern development. Aluminum hollow panels can be size-adjusted with redesigned elements rather than simple scaling. Standard size is 1200x2400mm, with larger sizes requiring panel combination.
Perforated Aluminum Metal Cladding Project Reference
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 39
Fence Decoration Applications
Powder Coated Laser Cut Aluminum Panel with Customizable RAL Colors and 3mm Thickness for Facade Cladding 40
