PVDF Coated 3D Metal Cladding Aluminum Facade Panel with Customizable Patterns in 1000x2000mm Size

As a professional manufacturer, M-City Aluminum maintains an excellent design team and skilled fabrication workers with advanced CNC facilities. We produce aluminum panels according to customer requirements for dimensions, specifications, shapes, structures, colors, and competitive budgets.

Our services include sending engineers to site for measurement and creating shop drawings to ensure smooth installation. All aluminum panels are prefabricated according to customer designs and drawings.

The metal cladding panel is manufactured from high-quality, high-strength aluminum alloy sheet with common thicknesses of 1.5mm, 2.0mm, 2.5mm, and 3.0mm. Maximum sheet dimensions are within 2000mm width and 6000mm length, using 3003-H14 or 1100-H14 aluminum alloy series.

The system consists of panel, reinforce bar, and bracket. Corner brackets can be directly stamped from the panel, bent and formed, or riveted on small folding edges. Reinforce bars connect to welding screws behind the board surface, creating a solid unit that enhances strength, rigidity, flatness, and resistance to wind pressure and earthquakes.

For sound insulation requirements, high-efficiency sound insulation materials can be installed inside the aluminum panel.

M-City Aluminum factory produces various metal facade panels with perforation or laser cut designs. We welcome requirements for your facade design projects.

Aluminum panels are manufactured from Aluminum alloy 3003 series. As a curtain wall system, they are used for wall protection and non-lighting walls, replacing mosaic and general sandblasting facades.

The light texture and excellent strength characteristics make these panels ideal for high-rise buildings, where they withstand various loads, particularly wind pressure. Traditional mosaic materials can easily fall off due to high wind pressure and deformation, while aluminum panels maintain structural integrity.

Aluminum hollow panels are used for facades, fences, canopies, ceilings, screens, windows, and other applications. You can choose patterns from our catalog or send drawings/pictures for custom design.

With imported CNC cutting machines, punching machines, professional software, experienced designers, and global project experience, you can trust us with your facade projects.

To meet individual customer requirements, you can select patterns from renderings or provide custom designs. Our standard size is 1200x2400mm, with custom sizing available through design element adjustment rather than simple scaling. Larger sizes require panel combination.
