Powder Coated Perforated Aluminum Cladding Panel - Customizable Solid Aluminum Wall Panel for Facade

Brand Name:	M-CITY
Model Number:	MCT-metal facades perforated
MOQ:	80square meters
Price:	USD25-USD55/square meter
Supply Ability:	60000sq.m

Detail Information

Product Description

Detail Information

Place of Origin:

Foshan, China

Certification:

ISO9000

Material:

Aluminum Alloy

Recommand Size:

1200x2400mm

Aluminum Thickness:

3mm,2mm, 2.5mm, 4mm To 10mm

Surface Treatment:

Powder Coated, Pvdf Paint, Wood Grain

Color:

Any RAL Color, Wood Grain, Stone Color, Brass, Bronze

Applications:

Window, Fence, Facade, Curtain Wall, Cladding, Decoration, Screen, Balcony

Max. Size:

1600x4000mm

Contact Email:

Mcityalu@163.com

Processing:

Cutting, CNC, Bending, Painting, Assmebly, Inspecting, Packing

Technology:

Perforated, Laser Cutting, CNC Turret Punching , Carved, Engraved

Keywords:

Metal Cladding Aluminum

Packaging Details:

Export packing, plywood cases, metal cases, protect film+ bubble film

Supply Ability:

60000sq.m

Highlight:

aluminum composite panel cladding

solid aluminum wall panels

aluminum facade cladding panels

Product Description

Aluminum Composite Panel Cladding Solid Aluminum Wall Panels

Professional aluminum composite panels and solid aluminum wall panels for modern architectural facades and building cladding applications.

3D Facade Design Metal Cladding

Perforated Aluminum Solid Panels

Aluminum Cladding Installation Guide

Corrugated Perforated Screen Aluminum Sheet

CNC Engraved Metal Facade Aluminum Sheet Assembly

Exterior Aluminum Decorative Panel with Round Holes Perforation

3D Facade Design Metal Clad Aluminum Facades Details

M-City Aluminum is a professional manufacturer with an excellent design team, skilled fabrication workers, and advanced CNC facilities. We produce aluminum panels according to customer requirements for dimensions, specifications, shapes, structures, colors, and competitive budgets. We can also send engineers to the site to measure installation specifications and work out shop drawings to help customers with smooth installation.

All aluminum panels are prefabricated according to customer designs and drawings. You only need to make a frame and prepare some bolts for installation, then use sealants to finish the gaps among panels. It is an easy job for building envelope and decoration.

The metal cladding panel is made of high-quality, high-strength aluminum alloy sheet with commonly used thicknesses of 1.5mm, 2.0mm, 2.5mm, and 3.0mm. The maximum sheet width is within 2000mm, maximum length within 6000mm, using aluminum alloy series 3003-H14 or 1100-H14. It consists of a panel, reinforce bar, and bracket. The corner bracket can be directly stamped from the panel, bent and formed, or riveted on the small folding edges of the panel. The reinforce bars are connected to welding screws behind the board surface, creating a solid whole that greatly enhances the strength and rigidity of the solid aluminum cladding panel, ensuring flatness and resistance to wind pressure and earthquake resistance in long-term use. For sound insulation requirements, high-efficiency sound insulation materials can be installed inside the aluminum panel.

M-City Aluminum Factory Workshop

Aluminum Cladding Containers Loading

M-City Aluminum factory produces all kinds of metal facade panels with perforation design or laser cut design. Welcome to send us requirements for your facade design.

3D Metal Facade for Wall Cladding Details

Frequently Asked Questions

Are you a trading company or factory?

We are a 100% professional manufacturer with more than 50 producing machines and over 100 staff members.

Can you accept our own designs?

Yes. Size, color, patterns/designs can be customized according to your project requirements.

What is your minimum order quantity?

We accept small orders with a minimum order quantity of 80 square meters.

What is the delivery time?

Orders will be completed within 30 days after receiving the deposit.

Contact Information

WhatsApp: +86 13631413050

Email: mcityalu@sina.com

Any patterns/design can be made - you can provide us with drawings or pictures.

M-City Metal Aluminum Facade Cladding Specifications

Aluminum panels are made of Aluminum alloy 3003 series. As a type of curtain wall, they are used for wall protection and non-lighting walls, replacing mosaic and general sandblasting facades. With their light texture and good strength characteristics, they offer advantages for high-rise buildings. Due to various loads experienced by high-rise buildings, especially wind pressure, mosaic materials can easily fall off because of large wind pressure and deformation. Aluminum panels, based on their unique advantages, can be widely used in high buildings.

Powder Coated Aluminum Facades

Aluminum hollow panels are used for facades, fences, canopies, ceilings, screens, windows, etc. You can choose patterns from our catalog or send us drawings or pictures - we can create designs for you.

CNC Cutting Machine Capabilities

With imported CNC cutting machines, punching machines, professional software and designers, and experience with various projects worldwide, you can feel confident when sending your projects to us.

To meet individual customer requirements, you can select patterns from renderings directly or choose your favorite patterns for customization. Our goal is to customize the best products for each customer. Aluminum hollow panels can be adjusted in size - not simply zoomed, but with design elements adjusted according to customer dimensions. Our standard size is 1200x2400mm; sizes larger than this require combination.

Perforated Aluminum Metal Cladding Project Reference

For Fence Decoration
